2'' x 2'' Lumber - 36" Length

Wood - Lumber

3

2'' x 2'' Lumber - 22" Length

Wood - Lumber

19

2'' x 2'' Lumber - 35.75" Length

Wood - Lumber

6

2'' x 2'' Lumber - 1.25" Length

Wood - Lumber

1

2'' x 2'' Lumber - 23.5" Length

Wood - Lumber

1

2'' x 4'' Lumber - 62.25" Length

Wood - Lumber

1

2'' x 4'' Lumber - 36" Length

Wood - Lumber

1

Small Door 26" x 3' for Chicken Coop

Wood - Lumber

1

2'' x 2'' Lumber - 28.25" Length

Wood - Lumber

1

2'' x 4'' Lumber - 37.5" Length

Wood - Lumber

1

2'' x 2'' Lumber - 8" Length

Wood - Lumber

4

2'' x 2'' Lumber with cut at 45° - 5.63" Length

Wood - Lumber

4

2'' x 2'' Lumber - 3.25" Length

Wood - Lumber

4

2'' x 2'' Lumber - 26" Length

Wood - Lumber

1

2'' x 2'' Lumber - 24.5" Length

Wood - Lumber

1

Corrugated Roof Panel 26'' x 12' - 24.5" Length

Plastic - Mixed

2

2'' x 2'' Lumber - 19.25" Length

Wood - Lumber

1

‍

1'' x 4'' Lumber with 2 cuts at 45° - 8.5" Length

Wood - Lumber

2

1'' x 4'' Lumber with 2 cuts at 45° - 12.75" Length

Wood - Lumber

2

1'' x 4'' Lumber with 2 cuts at 45° - 17" Length

Wood - Lumber

2

1'' x 4'' Lumber with 2 cuts at 45° - 21.25" Length

Wood - Lumber

2

1'' x 4'' Lumber with 2 cuts at 45° - 25.5" Length

Wood - Lumber

2

1'' x 4'' Lumber - 5" Length

Wood - Lumber

9

2'' x 4'' Lumber - 47.75" Length

Wood - Lumber

3

Side Door 2' x 4' for Chicken Coop

Wood - Lumber

1

2'' x 2'' Lumber - 11.75" Length

Wood - Lumber

1

2'' x 4'' Lumber - 1.5" Length

Wood - Lumber

1

Fence Wire 2' - 35.1" Length

Metal - Galvanized Steel

3

Fence Wire 2' - 5.85" Length

Metal - Galvanized Steel

5

1'' x 4'' Lumber - 50.5" Length

Wood - Lumber

5

1'' x 4'' Lumber - 15.25" Length

Wood - Lumber

3

1'' x 4'' Lumber - 25.5" Length

Wood - Lumber

1

1'' x 2'' Lumber - 15.25" Length

Wood - Lumber

1

1'' x 4'' Lumber - 13" Length

Wood - Lumber

1

Plywood Panel 4' x 8' - 24.5" Length

Wood - Lumber

1

‍

1'' x 4'' Lumber - 4.75" Length

Wood - Lumber

9

2'' x 2'' Lumber - 23.75" Length

Wood - Lumber

2

2'' x 2'' Lumber - 20.75" Length

Wood - Lumber

1

1'' x 4'' Lumber - 37.75" Length

Wood - Lumber

4

1'' x 4'' Lumber - 38.75" Length

Wood - Lumber

1

1'' x 4'' Lumber - 62.5" Length

Wood - Lumber

4

1'' x 4'' Lumber - 27" Length

Wood - Lumber

3

1'' x 2'' Lumber - 27" Length

Wood - Lumber

1

1'' x 4'' Lumber - 51.75" Length

Wood - Lumber

4

1'' x 4'' Lumber - 51.5" Length

Wood - Lumber

4

2'' x 4'' Lumber - 16.25" Length

Wood - Lumber

4

Corrugated Roof Panel 26'' x 12' - 29.75" Length

Plastic - Mixed

2

Fence Wire 2' - 16.38" Length

Metal - Galvanized Steel

2

Step 1

Let's begin by constructing the main frame, which will provide support for the entire structure of the chicken coop. It's important to note that we will focus on the roofed section of the coop for now, and we will address the exterior part later.

The base of the chicken coop consists solely of 2x4 wood profiles. The main frame comprises the following components:

• Two 2x4 profiles, each measuring 62.5 inches in length.
• Three 2x4 profiles, each measuring 47.75 inches in length.
• One of the 47.75-inch profiles should be separated at a distance of 38.5 inches to the right side. This separation serves the purpose of creating distinct internal areas within the poultry house.

To achieve a height of 26.25 inches above the floor level, four 2x4 profiles of the aforementioned length will be utilized.

Please note that these measurements and arrangements are specific to this particular coop design.

Step 2

Once you have successfully assembled the base or main frame of the chicken coop, it's time to work on the main structure of the roofed section. To accomplish this, you will need the following materials:

• Four 2x2 profiles with a 45-degree cut, measuring 39 inches in length.
• Four 2x2 profiles measuring 28.5 inches in length.
• One 2x2 profile measuring 47 inches in length.
• One 2x2 profile measuring 50.75 inches in length.

In reference to the provided diagram, the four profiles with a 45-degree cut should be positioned vertically at two of the ends of the base, as well as on two of the ends of the intermediate profile.

On top of these vertical profiles, place the 50.75-inch profile at the upper part, and on the right side, position the 47-inch profile.

At this point, the main structure is nearly ready to be covered, completing the roofed section of the chicken coop.

Step 3

Once the main structure is assembled, the next step is to cover the front and back of the chicken coop. For this, you will need the following materials:

• Fourteen profiles of 1x4, each measuring 5.25 inches in length.
• Four profiles of 1x4, each measuring 63.75 inches in length.
• Four profiles of 1x4, each measuring 28.75 inches in length.
• Five profiles of 1x4, each measuring 39 inches in length.
• Ten profiles of 1x4, each with two cuts at 45 degrees on each end.

We recommend referring to the 3D model we have provided to ensure the precise measurements for each piece with two cuts at 45 degrees. Reviewing the model will help clarify any doubts and provide you with more confidence as you proceed with the construction process.

Step 4

Once you have covered the back and front of the chicken coop with the wood profiles, the next step is to cover the left and right sides. For this, you will need:

• Sixteen profiles of 1x4, each measuring 51.7 inches in length.

These profiles will be placed in the empty spaces on the sides of the chicken coop, serving as protective barriers for the interior of the coop. Their purpose is to enclose the sides, ensuring the safety and security of the chickens inside.

Step 5

To complete the roofed section of the chicken coop, we will cover the remaining empty spaces using the following elements:

• Two sections of corrugated panels, each measuring 30 inches in length. These panels will provide additional coverage and protection against the elements.
• A small door measuring 26 inches by 3 feet. This door will serve as an entry point for easy access to the interior of the coop.
• A side door measuring 2 feet by 4 feet. This door will provide an additional entry or exit point.

With these additions, the roofed part of the chicken coop is now finished. We highly recommend applying a protective coating to the exterior wooden elements to prolong their durability. This recommendation also applies to doors made of wood, ensuring their longevity and functionality over time.

Step 6

After completing the roofed part of the chicken coop, it's time to construct the necessary frames for the exterior section. To accomplish this, you will need the following materials:

• Eight profiles of 2x2, each measuring 36 inches in length.
• Ten profiles of 2x2, each measuring 22 inches in length.
• Five profiles of 2x2, each measuring 45.5 inches in length.

As depicted in the diagram, the objective is to form three main frames using the 36-inch and 45.5-inch profiles. One of the frames needs to be positioned in the middle of the other two frames, and the separation between them will be determined by the 22-inch profile, which serves as a connecting piece for the three frames. It is important to securely fasten these connections both at the top and bottom of the frames for stability.

By assembling these frames, you will establish the structural framework for the exterior section of the chicken coop.

Step 7

In this final step, we will proceed to install the chicken wire to cover the empty spaces and ensure the safety of the hens. The required materials for this task are as follows:

• Six lengths of Fence Wire 2' with a length of 35 inches each.
• Two sections of Fence Wire 2' with a length of 48 inches each.

The purpose of this mesh is to securely enclose the coop and prevent the hens from escaping. By carefully placing and attaching the chicken wire, you will effectively create a secure and protected environment for your chickens.

Congratulations! With the completion of this step, you now have a fully functional chicken coop ready to house your feathered friends. Enjoy the benefits of your new coop and the comfort it provides for your hens.

‍
